Front:
Lock and Dam and Power House,
Greater Electrical Chattanooga,
Chattanooga Savings Bank,
Chattanooga, Tenn.
Hales Bar, Tennessee River
21 Miles from hattanooga.
COPYRIGHT 1910
RUDOLPH J. SHUTTING
CHATTANOOGA
Back:
1,50
LOCK AND DAM.
SHUTTING,
Domestic and
J.
RUDOLPH
CHATTANOOGA, TENN.
BY
12730—PUBLISHED
Thirty-three miles down the Ten-
nessee River from Chattanooga.
Twenty-one miles by Automobile Road
and Railroad. Seventeen miles by the
Transmission Line. Fifty-six Thou-
sand Horse Power. Length of Dam,
1,200 feet. More Water will pass over
this Dam than any other Dam on a
navigable river in the United States.
Head of water above Dam, 40 feet.
Lock dimensions inside, 60x300 feet.
Height of Lock walls, 59 feet. The
Lock is the highest single lift in the
world. Height of Down Stream
Gates, 58 feet. Power House 356 feet
long. Voltage of Transmission, 44,000
Volts.
