Manhattan Bridge Over the East River at New York City

Front:
Length of Middle Span Length of each Side Span....... Length, including Anchorages. Length, including Approaches.. Width (over all)...... MANHATTAN BRIDGE Over the East River at New York City 1,470 feet Capacity: 16,000 lbs. Live Load, per linear foot. Traffic Facilities: 725 feet .3,274 feet ..6,654 feet 124 feet Towers (pinnacle tops), height above Mean High Water, 400 feet Lower Deck: One Roadway, 35 feet 6 inches wide. Two Promenades, each having 11 feet 9 inches clear width. Four Trolley Tracks, Upper Deck: Four Elevated Railroad Tracks. No. 015 Published by The American News Company, New York-Leipzig-Berlin

Back:
DHE за 20
