Jackies from the U. S. SS. Utah recovering a
spent torpedo after target practice. A torpedo
is like a small, independent submarine. It is 21
feet long, 21 inches in diameter, and is divided
into six compartments. The first or front com-
partment contains damp gun cotton and detona-
tor which explodes the torpedo when it comes
into contact with anything solid, as a ship's
side. Second, compressed air tank containing
1,350 pounds
of air to drive the propellers.
Third, balance compartment from which project
horizontal planes. Fourth, engine compartment
containing turbine type motor driven by com-
pressed air. Fifth, buoyancy compartment, hold-
ing enough air to keep torpedo from sinking and
make it easily propelled. Sixth, gyroscope com-
partment to insure its continuance on the course
aimed. The torpedo also has horizontal and
perpendicular rudders which may be set at any
angle, and strong twin propellers.
